Class 11 Physics Chapter 14 Oscillations Notes

Badal May 24, 2020
Oscillations


Any motion, which repeats itself in equal intervals of time is called periodic motion. Oftenly, the displacement of a particle in periodic motion can always be expressed in terms of sine and cosine functions. Since the term harmonic is applied to expressions containing these functions, periodic motion is also called harmonic motion.
If a particle in periodic motion moves back and forth (or to and fro) over the same path, then its motion is called oscillatory or vibratory. The examples of oscillatory or vibratory motion are:
- the motion of a pendulum
- the motion of a spring fixed at one end, which is stretched or compressed and then released
- the motion of a violin string
- the motion of atoms in molecules or in a solid lattice
- the motion of air molecules as a sound wave passes by

Characteristics of a Harmonic Motion
The basic quantities characterizing a periodic motion are the amplitude, period and frequency of vibrations.
Amplitude (A)
The amplitude of oscillations is the maximum displacement of a vibrating body from the position of equilibrium.
Time Period (T)
The time period of oscillations is defined as the time between two successive identical positions passed by  the body in the same direction.
Frequency (f)
The frequency of oscillations is the number of cycles of vibrations of a body completed in one second. The frequency is related to the time period as
                              F = - {{dU} \over {dx}}
The SI unit of frequency is s-1 or Hz (Hertz)
In mechanical oscillations a body oscillates about its mean position which is also its equilibrium position. At the equilibrium position no net force (or torque) acts on the oscillating body. The displacement (linear or angular) of an oscillating particle is its distance (linear or angular) from the equilibrium position at any instant.
When a body oscillates along a straight line within two fixed limits; its displacement x changes periodically in both magnitude and direction; its velocity v and acceleration a also vary periodically in magnitude and direction, shown in figure. Since F = ma, therefore, the force acting on the body also varies in magnitude and direction with time.In terms of energy, we can say that a particle executing harmonic motion moves back and forth about a point at which the potential energy is minimum (equilibrium position). The force acting on the body at any position is given by
F =- {{dU} \over {dx}}
When a body is displaced from its equilibrium it is acted upon by a restoring force(or torque) which always acts to accelerate the body in the direction of its equilibrium position as shown in the figure.

SIMPLE HARMONIC MOTION

Let us consider an oscillatory particle along a straight line whose potential energy function varies as
                      U(x) = {1 \over 2}k{x^2}
where k is a constant
The force acting on the particle is given by
F =- {{dU} \over {dx}} = {{ - k} \over 2}{{d\left( {{x^2}} \right)} \over {dx}} =- kx
Such an oscillatory motion in which restoring force acting on the particle is directly proportional to the displacement from the equilibrium position is called Simple Harmonic Motion. The potential energy function of such a particle is represented by a symmetric curve as shown in the figure. Note that the limits of oscillation are equally spaced about the equilibrium position. This is not true for the motion shown in figure, which is harmonic, but not simple harmonic.
Applying Newton’s Second Law
F = ma = -kx
For the acceleration we can put  a = {{dv} \over {dt}} = {{{d^2}x} \over {d{t^2}}}
m{{{d^2}x} \over {d{t^2}}} =- kx  or
{{{d^2}x} \over {d{t^2}}} + \left( {{k \over m}} \right)x = 0.
The above equation is called the differential equation of SHM.
It gives a relation between a function of the time x(t) and its second derivative  {{{d^2}x} \over {d{t^2}}}.  To find the position of the particle as a function of the time, we must find a function x(t) which satisfies this relation.
It is obvious from a simple experiment as depicted in figure, in which an oscillating particle traces a sinusoidal curve on a moving strip of paper. In general, the equation of a simple harmonic motion may be represented by any of the following functions
x = A\sin (\omega t + \phi )
x = A\cos (\omega t + \phi )
x = A\sin \omega t + B\cos \omega t
Although  all the above three equations are the solution of the differential equation but we will be using x = A sin (w t + f) as the general equation of SHM.

Characteristics of SHM
- The amplitude A is constant
- The frequency and period are independent of the amplitude.
- This implies large oscillations have the same period as small ones.

In equation, the argument (wt+f) is called the phase, where f is called the phase constant. Both the phase and the phase constant are measured in radians. The value of f depends on the position wherefrom we start measuring time.
The characteristic of the differential equation is that it does not represent one single motion but a group or family of possible motions which have some features in common but differ in other ways.
In this case w is common to all the allowed motions, but A and f may differ among them. The amplitude A and the phase constant f of the oscillation are determined by the initial position and speed of the particle. These two initial conditions will specify A and f exactly.
One very important distinctive feature of SHM is the relation between the displacement, velocity and acceleration of oscillatory particle.
x = A sin wt
v = {{dx} \over {dt}} = \omega A\cos \omega t = \omega A\sin (\omega t + {\pi \over 2}) = \omega A\cos \omega t = \omega A\sin (\omega t + {\pi \over 2})
a = {{{d^2}x} \over {d{t^2}}} = - {\omega ^2}A\sin \omega t = {\omega ^2}A\sin (\omega t + \pi ) - {\omega ^2}A\sin \omega t = {\omega ^2}A\sin (\omega t + \pi )
Substituting the value of x in the above equation
or  {{{d^2}x} \over {d{t^2}}} = - {\omega ^2}x
or  {{{d^2}x} \over {d{t^2}}} + {\omega ^2}x = 0

This is the standard differential equation of SHM.
Notice that the maximum displacement is A, the maximum speed is wA, and the maximum acceleration is w2A.
The displacement, velocity and acceleration versus time graphs have been plotted in figure.
The velocity function is p/2 ahead of the displacement function and the acceleration function is p/2 ahead of the velocity function.

Conditions of Simple Harmonic Motion
For SHM to occur, three conditions must be satisfied.

There must be a position of stable equilibrium
 At the stable equilibrium, the potential energy is minimum.
{{dU} \over {dx}} = 0   and   0" />.

There must be no dissipation of energy

The acceleration is proportional to the displacement and opposite in direction.
That is,   a = -w2x

Application 1

The position of a particle moving along x – axis is given by x = 0.08 sin (12t + 0.3) m where t is in second.
(a)  What is the amplitude and the period of the motion?
(b)  Determine the position, velocity, and acceleration at t = 0.6 s.

Solution

(a)  On comparing the given equation with the standard equation of SHM,
i.e. y = A sin (wt + f), we see that the amplitude is A = 0.08 m and the angular frequency w = 12rad/s. Thus, the period  is T = 2p/w = 0.524 s.
(b)  The velocity and acceleration at any time are given by
v = 0.96 cos (12 t + 0.3) m/s
a =  -11.5  sin (12 t + 0.3) m/s2
At t = 0.6 s, the phase of motion is (12 \times 0.6 + 0.3) = 7.5 rad.
When this is used in the above expressions, we find
x = 0.075 m, v = 0.333 m/s, and a = -10.8 m/s2.

Spring Mass System

Let us find out the time period of a spring-mass system oscillating on a smooth horizontal surface as shown in the figure.
At the equilibrium position the spring is relaxed. When the block is displaced through x towards right, it experiences a net restoring force F = -kx towards left.
The negative sign shows that the restoring force is always opposite to the displacement. That is, when x is positive, F is negative, the force is directed to the left. When x is negative, F is positive, the force is directed to the right. Thus, the force always tends to restore the block to its equilibrium position x = 0.
so  F = -kx
Applying Newton’s Second Law,
F = m{{{d^2}x} \over {d{t^2}}} =- kx
or  {{{d^2}x} \over {d{t^2}}} + \left( {{k \over m}} \right)x = 0
Comparing the above equation with standard equation, we get
{\omega ^2} = {k \over m}  or T = 2\pi \sqrt {{m \over k}}
Note that the time period is independent of the amplitude. For a given string constant, the period increases with the mass of the block – a more massive block oscillates more slowly. For a given block, the period decreases as k increases. A stiffer spring produces quicker oscillations.

Application 2

Find the period of oscillation of a vertical spring-mass system.

Solution

Let xo be the deformation in the spring in equilibrium.
Then    k\mathop x\nolimits_0  = mg
When the block is further displaced by x, the net restoring force is given by
        F = -[k(x + xo) – mg]
or     F = -kx
(because kxo= mg)
Using second law of motion,
m{{{d^2}x} \over {d{t^2}}} = - kx
or {{{d^2}x} \over {d{t^2}}} + \left( {{k \over m}} \right)x = 0
Thus,  {\omega ^2} = {k \over m}  or  T = 2\pi \sqrt {{m \over k}}

Note that gravity does not influence the time period of the spring-mass system, it merely changes the equilibrium position

Series and Parallel Combinations of Springs

When two springs are joined in series, the equivalent stiffness of the combination may be obtained as
                 {1 \over k} = {1 \over {{k_1}}} + {1 \over {{k_2}}}
When two springs are joined in parallel, the equivalent  stiffness of the combination is given by
                  k = k1 + k2Application 3

Two masses m1 and m2 are suspended together by a massless spring of spring constant k. When the masses are in equilibrium m1 is removed without disturbing the system. Find the angular frequency and amplitude of oscillation of m2.

Solution

As m1 is removed, the mass m2 will oscillate and so
T = 2\pi T = 2\pi \sqrt {{{{m_2}} \over k}}   i.e. \omega=\omega= {{2\pi } \over T} = \sqrt {{k \over {{m_2}}}}
Furthermore, the stretch produced by m1g will set an amplitude,
i.e.   m1g = kA
i.e.   A = (m1g/k)

Application 4

For the arrangement shown in the figure, find the period of oscillation.

Solution

Obviously, when the block is displaced down by x, the spring will stretch by {x \over 2}.
From the free body diagram of the pulley,
{{kx} \over 2} = 2T or
T = {{kx} \over 4}
The net restoring force on the block is T.
Using the Second Law of motion, we get
m{{{d^2}x} \over {d{t^2}}} = - T = - {{kx} \over 4} or
{{{d^2}x} \over {d{t^2}}} + \left( {{k \over {4m}}} \right)x = 0
Thus, the period of SHM is given by
 T = 2\pi \sqrt {{{4m} \over k}}
Note that we have not taken gravity into account as it does not affect the time period.

Application 5

 The angular displacement of simple pendulum is given by
 \theta= 0.1\pi \sin \left( {2\pi t + {\pi\over 6}} \right)rad
 The mass of the bob is 0.4 kg. Calculate
 (a)  the length of the simple pendulum;  and
 (b)  the velocity of the bob at t = 0.25 s

Solution

(a)  We are given  \mathop \theta \nolimits_0= 0.1\pi rad,  \phi= {\pi\over6}rad, and \omega= 2\pi rad/s. Since w2 = (g/L),
       we have
       L = {g \over {{\omega ^2}}} = {{9.8m/{s^2}} \over {{{\left( {2 \times3.14rad/s}\right)}^2}}} = 0.25m
(b)  Since s = L\theta , the velocity of the bob,v = {{ds} \over {dt}} is
       v = L{{d\theta } \over {dt}} = (0.25m)(0.1\pi )(2\pi )\cos ({\pi\over 2} + {\pi\over 6})=-0.123m/s =(0.25)(0.1\pi )(2\pi )\cos \left( {{\pi\over 2}+{\pi\over 6}} \right) =- 0.123m/s

Pendulums

Simple Pendulum

Ideally, a simple pendulum consists of a point mass suspended at the end of a massless string as shown in the figure.
At the equilibrium position, net torque about the point ‘O’ is zero, at \theta= 0.
When the pendulum is displaced through an angle q, the restoring torque about the point O is given by
to = -mgl sin\theta
For small angles sin\theta\approx \theta , therefore,
to = -mgl\theta
Using Newton’s Second Law,
{\tau _0} = {I_0}\alpha= m{l^2}{{{d^{\backslash 2}}\theta } \over {d{t^2}}}
Thus,        {{{d^2}\theta } \over {d{t^2}}} + \left( {{g \over l}} \right)\theta= 0
Comparing the above equation with the standard differential equation, we get
{\omega ^2} = {g \over l}
T = 2\pi \sqrt {{l \over g}}
The pendulum having a time period equal to two seconds is called a second’s pendulum.

Physical Pendulum

In figure, an extended body is pivoted freely about an axis that does not pass through its center of mass. Such an arrangement forms a physical pendulum that executes simple harmonic motion for small angular displacements. If d is the distance from the pivot to the center of mass, the restoring torque is –mgd sin\theta .
Using Newton’s Second law, \tau= I\alpha ,
we get
- mgdsin\theta= I{{{d^2}\theta } \over {d{t^2}}}
Where I is the moment of inertia about the given axis. If we use the small-angle approximation, sin\theta\approx \theta , then
{{{d^2}\theta } \over {d{t^2}}} + {{mgd}\over I}\theta=0
Thus,      \omega=\sqrt {{{mgd} \over I}}   and   T = 2\pi \sqrt {{I \over {mgd}}}
If the location of the center of mass and d are known, then a measurement of the period allows us to determine the moment of inertia of the body.

Application 6

A rod of mass M and length L is pivoted about its end O as shown in the figure. Find the period of SHM.

Solution

Restoring torque is
{\tau _0} = Mg{L \over 2}\sin \theta
Using Newton’s Second Law   and the small angle approximation, we get
{I_0}{{{d^2}\theta } \over {d{t^2}}} + Mg{L \over 2}\theta= 0
Using parallel-axes theorem
{I_0} = {I_c} + M{\left( {{L \over 2}} \right)^2} = {{M{L^2}} \over {12}} + {{M{L^2}} \over 4} = {{M{L^2}} \over 3}
{{{d^2}\theta } \over {d{t^2}}} + \left( {{3 \over 2}{g \over L}} \right)\theta= 0
{{{d^2}\theta } \over {d{t^2}}} + \left( {{3 \over 2}{g \over L}} \right)\theta= 0
Thus, T = 2\pi \sqrt {{{2L} \over {3g}}}

Application 7

A simple pendulum of length L and mass m has as spring of force constant k connected to it at a distance h below its point of suspension. Find the frequency of vibrations of the system for small values of amplitude.

Solution

As shown in figure, if the pendulum is given a small angular displacement q, the spring will also stretch by y( = h\tan \theta ). So there restoring torque about O will be due to both force of gravity and elastic force of the spring.
i.e \tau=- [mg(L\sin \theta ) + k(h\tan \theta )h]
Now for small\theta  ,
\tan \theta= \sin \theta= \theta
so, t = -(mgL + kh2)\theta
i.e. restoring torque is linear, so motion
is angular SHM.
Now as \tau= I\alpha= m{L^2}{{{d^2}\theta } \over {d{t^2}}}
(as I = mL2)
so m{L^2}{{{d^2}\theta } \over {d{t^2}}} =- {\omega ^2}\theta
with  {\omega ^2} = \left[ {{{mgL + k{h^2}} \over {m{L^2}}}} \right]
This is the standard equation of angular SHM with frequency f = (w/2p); so here
f = {1 \over {2\pi }}\sqrt {{{mgL + k{h^2}} \over {m{L^2}}}}

Application  8

Suppose a tunnel could be dug through the earth from one side to the other along a diameter, as shown in figure. Show that the motion of the particle is simple harmonic and determine its time period.

Solution

The gravitational force on the particle at a distance r from the centre of the earth arises entirely from that portion of matter of the earth in shells internal to the position of the particle. The external shells exert no force on the particle.
The value of gravity at a distance r is given by
where {g_0} = {{GM} \over {{R^2}}} is the gravity on the surface of earth.
The net force on the particle is
F = -mg = -mgo {r \over R}
Using  Newton’s Law,
F = m{{{d^2}r} \over {d{t^2}}} = {{ - m{g_o}} \over R}r
or {{{d^2}r} \over {d{t^2}}} + \left( {{{{g_o}} \over R}} \right)r = 0
This is the differential equation of SHM.
The period of oscillation is
T = 2\pi \sqrt {{R \over {{g_o}}}}
Taking R = 6400 km  = 6.4 ´ 106 m   and   go = 9.81 m/s2,  we get
T = 84.2 min.

Application 9

An ideal liquid of density r occupies length l of an U – tube of uniform cross-section as shown in the figure given below. When the liquid surface is displaced through x the liquid column executes SHM. Find the period of oscillation.

Solution

When the liquid column is displaced through x on the right side, the weight of the unbalanced liquid provides the restoring force.
F =- [\rho A(2x)]g
where A is the area of cross-section
Applying Newton’s second law
F = m{{{d^2}x} \over {d{t^2}}} = \left( {\rho \,Al} \right){{{d^2}x} \over {d{t^2}}}
(\rho Al){{{d^2}x} \over {d{t^2}}} + \rho \,A\left( {2x} \right)g = 0
or {{{d^2}x} \over {d{t^2}}} + \left( {{{2g} \over l}} \right)x = 0
Time period is  T = 2\pi \sqrt {{l \over {2g}}}

Energy conservation in SHM

In a spring-mass system, the instantaneous potential energy and kinetic energy are expressed as
and u = {1 \over 2}k{x^2} = {1 \over 2}k{A^2}{\sin ^2}\left( {\omega \,t + \varphi } \right)
Since  {\omega ^2} = {k \over m}
K = {1 \over 2}k{A^2}{\cos ^2}\left( {\omega \,t + \varphi } \right)
The total mechanical energy is given by
E = K + U
E = {1 \over 2}k{A^2}\left[ {{{\sin }^2}\left( {\omega \,t + \varphi } \right) + {{\cos }^2}\left( {\omega \,t + \varphi } \right)} \right]
or E = {1 \over 2}k{A^2}=constant
Thus, the total energy of SHM is constant and proportional to the square of the amplitude.
The variation of K and U as function of x is shown in figure When x = ±A, the kinetic energy is zero and the total energy is equal to the maximum potential energy.
E = {u_{\max }} = {1 \over 2}k{A^2}
There are extreme points or turning points of the SHM.
At        x = 0, U = 0  and the energy is purely kinetic,
E = {K_{\max }} = {1 \over 2}m{\left( {\omega A} \right)^2}

The variation of K and U as function of t is shown in figure. Note that the frequency of variation of the kinetic and potential energy is twice that of the frequency of oscillation.
The instantaneous total mechanical energy of the spring-mass system may be written as
E = {1 \over 2}m{v^2} + {1 \over 2}k{x^2}=constant
Differentiating it w.r.t. time, we get
{{dE} \over {dt}} = {1 \over 2}m{d \over {dt}}\left( {{v^2}} \right) + {1 \over 2}k{d \over {dx}}\left( {{x^2}} \right)
or  0 = mv{{dv} \over {dt}} + kx{{dx} \over {dt}}
since  v = {{dx} \over {dt}}  and  {{dv} \over {dt}} = {{{d^2}x} \over {d{t^2}}} therefore,
{{{d^2}x} \over {d{t^2}}} + {k \over m}x = 0
This is the differential equation of SHM.

Application 10

A solid cylinder of mass M and radius R is attached to a spring of stiffness k as shown in the figure. The cylinder can roll without slipping on a rough horizontal surface. Show that the centre of mass of the cylinder executes SHM and determine its time period.

Solution

Consider the situation when the spring is extended by x.
The total energy of the cylinder plus spring system is
E = {1 \over 2}M{v^2} + {1 \over 2}I{\omega ^2} + {1 \over 2}k{x^2}=constant
Here, I = {1 \over 2}M{R^2}  and  \omega={v \over R}
{3 \over 4}M{v^2} + {1 \over 2}k{x^2} = constant
Differentiating w.r.t. time, we get
{3 \over 4}M2v{{dv} \over {dt}} + {1 \over 2}k2x{{dx} \over {dt}} = 0
nothing that v = {{dx} \over {dt}}
and {{dv} \over {dt}} = {{{d^2}x} \over {d{t^2}}}
we get {{{d^2}x} \over {d{t^2}}} + {{2k} \over {3M}}x = 0
so, T = 2\pi \sqrt {{{3M} \over {2k}}}






Post a Comment

0 Comments

Emoji
(y)
:)
:(
hihi
:-)
:D
=D
:-d
;(
;-(
@-)
:P
:o
:>)
(o)
:p
(p)
:-s
(m)
8-)
:-t
:-b
b-(
:-#
=p~
x-)
(k)
