Class 12 Physics Chapter 12 Atoms Notes

Atoms

Structure Of An Atom

All matter is made up of tiny particles known as atoms. There are only about 105 different kinds of atoms, and they combine with each other in different ways to form groups called molecules. All matter has been found to be composed of atoms or molecules, and some knowledge of how atoms are made will give us valuable information about the behaviour of matter.

Thomson's Atomic Model

On the basis of his experiments J.J. Thomson proposed a model of internal atomic structure according to which atom consisted of positively charged substance (+ve electric field) distributed uniformly over the entire body of the atom, with negative electrons embedded in this continuous positive charge like seeds in a watermelon. It was a good effort to reveal mystery of an atom but it was not the true picture of an atom

Rutherford's Atomic Model

The correct description of the distribution of positive and negative charges within an atom was made in 1911 by a New Zealander when working at Manchester University in England. This was Ernest Rutherford, who was later called as Lord Rutherford for his many scientific achievements. He entered into physics during that crucial period of its development when the phenomenon of natural radioactivity had just been discovered, and he was first to realize that radioactivity represents a spontaneous disintegration of heavy unstable atoms.
Rutherford realized that important information about the inner structure of atoms could be obtained by the study of collisions between on rushing a particles and the atoms of various materials forming the target.

The basic idea of the experimental arrangement used by Rutherford in his studies was explained as follows:
A speck of α-emitting radioactive material; a lead shield with a hole that allowed a narrow beam of the α - particles to pass through; a thin metal foil to deflect or scatter them; and a pivoted fluorescent screen with a magnifier through which the tiny flashes of light were observedwhenever an α -particle struck the screen. The whole apparatus was evacuated, so that the particles would not collide with air molecules.

Observations of Rutherford

Most of the α-particles penetrated the foil with very little deflection. An appreciable fraction of them were deflected through large angles - a few were turned back almost as though they had been reflected from the foil. This was a deflection of nearly 180° and a completely impossible phenomenon according to the Thomson's model
Such large deflections required strong forces to be acting, such as those between very smaller charged particles very close together. This would be possible, Rutherford reasoned, if all the positive charge, along with most of the atomic mass, were concentrated in a very small central region which Rutherford called the atomic nucleus.

Because there would be a coulomb force of attraction between the positive nucleus and the negative electrons, the two would be down together and the atom would vanish unless some provisions were made to prevent it. It was suggested that the electrons might be orbiting rapidly around the nucleus, so that the electrostatic attraction would merely provide the necessary centripetal force.

Drawbacks of the Rutherford model

(i)   Rutherford's atomic model was unable to make any predictions about the light that an atom would emit
(ii)  More serious than this was its conflict with the accepted laws of electromagnetic theory. An electron revolving rapidly around a nucleus must have a continual centripetal acceleration, and this acceleration would cause a continuous loss of energy by radiation. Bohr calculated that this emission of radiation would cause the electrons in an atom to lose all their energy and fall into the nucleus within a hundred - millionth of a second. Since matter composed of atoms exists permanently, as far as we know, there was obviously something wrong here.

Bohr’s Theory of The Hydrogen Like Atoms

Bohr’s theory applies to hydrogen atom and species like He+, Li++ etc. Here a single electron revolves around a stationary nucleus of positive charge Ze where Z = 1 for hydrogen atom, Z = 2 for He+ etc.

Bohr in defiance of the well - established laws of classical mechanics and electrodynamics, proposed the following postulates:
1. Of all the infinite number of mechanically possible orbits for an electron revolving around a nucleus, only a few are permitted. These are the orbits in which the angular momentum of the electron is an integral multiple of h2π, where h is the planck’s constant
2. While circling around these permitted orbits, the electrons do not emit any electromagnetic radiation, even though conventional electrodynamics holds that they should
3.Electrons may jump from one orbit to another, in such case the difference in energy between the two states of motion is radiated as a photon whose frequency is determined by the quantum rule

ΔE=hv

Bohr's Orbits

For an electron orbiting in a hydrogen like atom, the necessary centripetal force is the electrostatic attraction between the negative electron and the massive, positively-charged nucleus
Thus,   kZe2r2=mv2r or r=kZe2mv2 (i)
According to Bohr's theory
mvr=nh2π        where, n = 1, 2, 3
r=nh2πmv            (ii)
From (i) and (ii)
v=2πkZe2nh   and      r=n2h24π2kmZe2

Energy of the Atom

The electron revolving around the nucleus has kinetic energy

k=12mv2=m2(2πkZe2nh)2=2π2k2mZ2e4n2h2

The electrostatic potential energy is

U=ke2r=−ke2(4π2kmZe2n2h2)=−4π2k2mZ2e4n2h2

Notice that the magnitude of  potential energy is double the magnitude of  kinetic energy.
Total energy of the atom is
E = K + U=1n2(2π2k2mZ2e4h2)
Putting the values ofk=9×109 Nm2/C2
e=1.6×10−19 C and h=6.63×10−34 Js,  we get
E=Z2n2(2.1810−18)J=−13.6Z2n2eV
(2.1810−18)J=−13.6Z2n2eV
An energy level diagram for the hydrogen atom (Z = 1) is shown in the figure. The vertical axis represents energy. The (arbitrary) zero of energy is taken as the energy of a stationary electron, infinitely far from the positive nucleus. The lowest energy level
(n = 1) is known as the ground state. The energy level corresponding to n = 2 is called the  first excited state and so on .  In this diagram zero energy level corresponds to
n =∞ which is the ionized state of the atom

Radiations Emitted by the atom

From the third rule of Bohr’s, a photon is emitted when an electron makes a transition from a higher sate to  a lower state. The difference between the two energy states is the energy of the emitted photon. Thus
ΔE=E2−E1=hv
Using the energy equation
DE = 2.18×10-18 Z2
v=ΔEh=3.29×1015Z(1n21−1n22)Hz
Dividing the above equation by c = 3×108 m/s, we get
1λ=3.29×10153×108[1n21−1n22]m-1
or 1λ=R∞[1n21−1n22]
where R∞= Rydberg constant =1.097×107m−1

The various transitions for the hydrogen atom  are shown in the following figure. All transitions starting from n = 2 onwards and ending at n = 1 belong to the Lyman Series. Likewise, all transitions starting from n = 3 onwards and ending at n = 2 belong to the Balmer Series. The other spectral series’ names are mentioned in the figure

Successes and Limitations of the Bohr Model

Bohr showed that Planck's quantum idea was a necessary part of the atom and its inner mechanism; he introduced the idea of quantized energy levels and explained the emission or absorption of radiation as being due to the transition of an electron from one level to another. As a model for even multielectron atoms, the Bohr picture is still useful. It leads to a good, simple, rational ordering of the electrons in larger atoms and qualitatively helps to predict a great deal about chemical behaviour and spectral details.

Bohr's theory is unable to explain the following facts:
1.The spectral lines of hydrogen atom is not a single line but a collection of several lines very close together.
2.The structure of multielectron atoms is not explained.
3.No explanation for using the principle of quantisation of angular momentum.
4.No explanation for Zeeman effect
If a substance which gives a line emission spectrum is placed in a magnetic field, the lines of the spectrum get split up into a number of closely spaced lines
This phenomenon is known as Zeeman effect.
The above discussion may be summarized as follows:
The atom consists of a heavy positively charged nucleus and negatively charged electrons moving around it. The electron is an elementary particle having a mass me≈9.1×10−31kg and a charge -e, e being an elementary charge approximately equal to 1.60×10−19C.

The nuclear charge is equal to +Ze, where Z is the atomic number. The atom contains Z electrons, their total charge being -Ze. Consequently, the atom is an electrically neutral system. The size of the nucleus varies depending on Z from 10-13 cm to 10-12 cm. The size of the atom is a quantity of the order of  10-8 cm.

The energy of the atom is quantized. This means that it can assume only discrete (i.e. separated by finite gaps) values: E1, E2, E3,…, which are called the energy levels of the atom
(E1 < E2 < E3 < …). Atoms with different Z's have different sets of energy levels

In a normal (unexcited) state, the atom is on the lowest possible energy level. In such a state, the atom may stay for an infinitely long time. By imparting an energy to the atom, it is possible to transfer it to an excited state with an energy higher than the energy of the ground state. A transition of the atom to a higher energy level may occur as a result of absorption of a photon or as a result of a collision with another atom or a particle, say, an electron

Excited states of the atom are unstable. The atom can stay in an excited state for about 10-8 s. After that the atom spontaneously (by its own) goes over to a lower energy level, emitting in this process a photon with an energy
Eik=hvik (i > k),

where i is the number of the energy level in the initial state and k is the number of the level to which a spontaneous transition of the atom occurred. For example, an atom which is in an excited state with the energy E3 can return to the ground state either directly, by emitting a photon of frequency
n31 = (E3 - E1)/h, or through an intermediate state with the energy E2, as a result of which two photons with frequencies n32 = (E3 - E2)/h and n21 = (E2 - E1)/h are emitted.

Important Formulae

1. Radius of nth orbit

    rn=0.53n2ZA∘   where Z = atomic number

2. Velocity of the electron in the nth orbit

     vn=Zn(c137)  where c = 3 x 108 m/s

3.  Energy of the electron in the nth orbit

En=−13.6Z2n2 (eV)
En=−(2.1810−18)Z2n2 (J)
E=K+U
K=−E=−U2
U=2E=−2K

4. Wavelength of photon emitted for a transition from n2 to n1

1λ=R∞Z2[1n21−1n22]
where {R_\infty } = 1.096 x 107 m-1 (for a stationary nucleus)
If nucleus is not considered to be stationary
R=R∞1+mM
where m is the mass of electron and M is the mass of nucleus

 5. Wavelength (Å) of a photon of energy E (eV) is given by

λ=12400E(eV)A0

 6.Momentum of a photon of energy E

ρ=Ec

Example 1

A single electron orbits around a stationary nucleus of charge +Ze, where Z is a constant and e is the magnitude of electronic charge. It requires 47.2 eV to excite the electron from second Bohr orbit to the third Bohr orbit.
(a) Find the value of Z
(b)  Find the energy required to excite the electron from n = 3 to n = 4
(c)  Find the wavelength of radiation required to remove electron from first Bohr’s Orbit to infinity.
(d)  Find the kinetic energy, potential energy and angular momentum of the electron in the first Bohr orbit.

Solution

(a) Given DE23 = 47.2 eV
      Since ΔE=13.6Z212400ΔE=12400340=36.47A0eV
      47.2=13.6Z2  ΔE=13.6Z212400ΔE=12400340=36.47A0 ⇒Z=5

(b) To find DE34;   n1 = 3;     n2 = 4
     ΔE=13.6Z2(1n21−1n22)
     ΔE=13.652(132−142)=16.53eV

(c)  Ionization energy is the energy required to excite the electron from n = 1 to n =∞
      Thus,ΔE=13.6×52(112−1∞2)= 340 eV
      The respective wavelength is
      λ=∞=12400ΔE=12400340=36.47A0z

(d) K = -E = +340 eV
     U = 2E = -680 eV
  L=h2π=6.63×10−342π=1.056×10−34J−s=6.63×10−342π=6.63×10−342π=1.056×10−34 J-s
